K-Tuned 12-15 Civic Si Angled Upper Coolant Housing
Part Number: KUW-24Z-N01

Images may be for reference only

$169.99

Earn 340 reward points. Learn More

10+ In Stock

Product Details

Part Number:	KUW-24Z-N01
Brand:	K-Tuned

K-Tuned Upper Coolant Housing for the K24Z series engines will provide several unique advantages over the stock units. The hose outlet on the K-Tuned housing pivots slightly, allowing approximately 15 degrees of angle adjustment. This is helpful when compared to the fixed the factory outlet that always seems to put the upper rad hose in the path of the intake piping. There are three available hose outlets to work with any radiator hose setup. Choose the standard 1.25" rad hose outlet for use with regular rubber or silicone rad hoses.

We have also designed an optional Filler Neck that can be used to relocate the radiator cap to a higher point on the engine itself. The new location is the highest point of the cooling system and allows air pockets to easily escape during the coolant bleeding process. The optional Filler Neck is also available with standard 1.25" hose or in 16AN sizes and was designed for use with an OEM 92-00 Honda Civic radiator cap. This part will be very helpful on an engine that already has a bad reputation for coolant bleeding.

The K-Tuned Upper Coolant Housing will compliment our Swivel Neck Thermostat and our Water Pump Block off Plate. All of these parts allow plenty of options for custom and race engine cooling setups.

Applications:

K24Z Series Engines

Features:

-16OR (O-Ring) and Hose End 1.25

Note:

Will NOT work with K24A1 and K24Y Series Engines
May Have fitment issues with turbos depending on size of turbo and manifold
Rad cap is not included

Due to the manufacturer's price control policy, this item may be excluded from promotions and discounts

WARNING: This product may contain chemicals known to the State of California to cause cancer or birth defects. www.P65Warnings.ca.gov.

Vehicle Fitment

Acura ILX

2013 Acura ILX Base
2014 Acura ILX Base

Acura TSX

2009 Acura TSX Base
2010 Acura TSX Base
2011 Acura TSX Base
2012 Acura TSX Base
2013 Acura TSX Base
2014 Acura TSX Base

2012 Acura TSX Special Edition
2013 Acura TSX Special Edition
2014 Acura TSX Special Edition

Honda Accord

2011 Honda Accord EX

2009 Honda Accord EX-L
2010 Honda Accord EX-L

2008 Honda Accord LX
2009 Honda Accord LX
2010 Honda Accord LX
2011 Honda Accord LX
2012 Honda Accord LX

2008 Honda Accord LX-P
2009 Honda Accord LX-P
2010 Honda Accord LX-P
2011 Honda Accord LX-P
2012 Honda Accord LX-P

2008 Honda Accord LX-S
2009 Honda Accord LX-S
2010 Honda Accord LX-S
2011 Honda Accord LX-S
2012 Honda Accord LX-S

2011 Honda Accord SE
2012 Honda Accord SE

Honda CR-V

2007 Honda CR-V EX
2008 Honda CR-V EX
2009 Honda CR-V EX
2010 Honda CR-V EX
2011 Honda CR-V EX
2012 Honda CR-V EX
2013 Honda CR-V EX
2014 Honda CR-V EX

2007 Honda CR-V EX-L
2008 Honda CR-V EX-L
2009 Honda CR-V EX-L
2010 Honda CR-V EX-L
2011 Honda CR-V EX-L
2012 Honda CR-V EX-L
2013 Honda CR-V EX-L
2014 Honda CR-V EX-L

2007 Honda CR-V LX
2008 Honda CR-V LX
2009 Honda CR-V LX
2010 Honda CR-V LX
2011 Honda CR-V LX
2012 Honda CR-V LX
2013 Honda CR-V LX
2014 Honda CR-V LX

2011 Honda CR-V SE

Honda Civic

2012 Honda Civic Si
2013 Honda Civic Si
2014 Honda Civic Si
2015 Honda Civic Si
