Product Details
| Part Number: | 856804-5004S |
| Brand: | Garrett Turbos |
| Turbo Flange: | V-band |
| Exhaust Housing: | .83 A/R |
| Turbine Discharge Flange: | 3" V-Band |
| Turbocharger Series: | GT35 |
*V-band compressor outlet*
Horsepower: 550 - 1000
Displacement: 2.0L - 5.5L
Features:
- GEN 2 AERODYNAMICS FEATURE INCREASED HORSEPOWER RANGE
- "RS" DESIGNED, HIGH HORSEPOWER TURBINE WHEEL
- COMPACT DESIGN FOR TIGHT INSTALLATIONS
- NEW FULLY-MACHINED SPEED SENSOR PORT.
- SOLD AS ASSEMBLY KITS (SUPER CORE + TURBINE KIT)
- COMP OUTLET AVAILABLE IN V-BAND & HOSE CONNECTION
| Compressor | Turbine | |||||||
|---|---|---|---|---|---|---|---|---|
| Super Core Reference Data | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| GTX3584RS Hose Bead Comp Outlet | 67mm | 84mm | 64 | 0.72 | 68mm | 62mm | 84 | |
| GTX3584RS V-Band Comp Outlet | 67mm | 84mm | 64 | 0.72 | 68mm | 62mm | 84 | |
